Embrace Luxury, Efficiency, and Solid Capabilities with a Strong New Jeep Compass
One of the most multipurpose crossover sport utility vehicles (SUVs) out there, the Jeep Compass also has the honor of being part of the most affordable. Completely qualified serving as a family automobile or a vehicle for an individual who is always on the move, the new Compass is centered around conforming to anything you throw at it. If you suppose this SUV might be the correct selection for you, come meet with us at Jacksonville CJDR Westside, so we can talk about all of the leasing and buying options for the newest Compass.
Pair Premium Handling with Intriguing Style in a Redesigned Jeep Compass
The Compass shows off one of the most eye-catching silhouettes of any SUV. Its appearance, accentuated by modern, glossy curvatures, is a distinctive blend of muscularity and posh. You can tailor the already striking look of the Compass by choosing from a plethora of two-tone or monotone outward paints and highlight your choice of color with either 18-inch (in.) by 7.0-in. gray pocket aluminum rims or 19-in. by 7.5-in. black pocket aluminum rims. Add some extra panache to the Compass by integrating the offered painted gloss black roof and all-the-way-around chrome molding, seeing to it that you will garner the interest of other car owners wherever you drive.
Step up Your Next 4x4 Escapade with the Power of Trailhawk
If you intend on utilizing your Compass for outdoor activities while traversing Jacksonville FL, consider opting for the Trailhawk trim level. Developed particularly for tough outdoor travels, the Trailhawk version contains skid plates, raised ground clearance, and tow hooks in order to keep you prepared for anything you come across off the pavement. Once considering this, driving the ground less used in Jacksonville clearly starts with modifying the Jeep Compass under your name through the Trailhawk model.
Giving You Usefulness That Leaves the Competition in Amazement
One of the qualities that makes this SUV really useful is its aptitude at handling numerous functions. If you are often lacking cargo space in your automobile, the latest Compass has the solution to that predicament. Being able to rearrange sitting spots via the rear chairs that lay down level in a 60/40 divide means you can give yourself that excess storage area when you require it. The front passenger chair can also fold down level, which is great when you are transporting a piece of equipment that has added length than normal. When you add the adjustable cargo floor with three differing levels, you basically have the solution to all storage issues. There are also a few other areas where you can store your items during road trips, including mesh side pockets, which is fantastic for cutting down bothersome piles if you have multiple riders.
Get More Out of Your Daily Drive with the Ideal Jeep Compass Trim Package
Jeep Compass Altitude
Choose the compact SUV that displays fearlessness and edginess in the city and on dirt paths. Compass Altitude embodies coolness with 18-in. black aluminum wheels, a slick gloss black roof encompassing side railing, big black grille, and piano black cabin trimmings. Moreover, Remote Proximity Keyless Entry and Push-Button Start make it easier for you to access the inside and turn on the engine.
Jeep Compass Latitude
As the supreme environment for luxury travels, Compass Latitude increases thoughts on cabin contentment and impressive craftsmanship through black higher-quality cloth/vinyl bucket seats, a steering wheel and shift knob covered in leather, ambient LED lighting illuminating softly, and more standard features of sophistication. Besides all of this, imagine opening up the available dual-pane sunroof to take in the loveliness of nature and wonderful weather.
Jeep Compass Sport
Venture out past the normal concrete roads and transport just about whatever you would like to bring. The wallet-friendly Compass Sport is powered by a 2.4-liter (L) Tigershark MultiAir 2 motor with segment-leading 4x4 highway fuel economy and maximum towing capacity of 2,000 pounds (lbs.). You can push the 60/40 rear chairs level and move the amendable cargo floor up or down to clear off increased room for your items, as well.
Jeep Compass Highlights
Luxurious Inner Add-ons That Keep You Cozy for Endless Trips
It is accurate to point out the newest Jeep Compass SUVs for sale or lease at Jacksonville CJDR Westside grasp plenty about keeping you comfy, anywhere the path takes you. In fact, if you want to travel in complete luxury, go with the optional leather-trimmed, warmed seating. A heated steering wheel is a fantastic addition, as well. Adding to this, both you and your front-seat passenger can change the temperature controls to the individual degrees you prefer.
The Driver Information Digital Cluster Display from Jeep Ensures You Routinely Remain in Control
The 7.0-in. Driver Information Digital Cluster Display, fully customizable, lets you adjust all of the graphics and settings to match your needs. In conjunction with vital data, like speed and revolutions per minute (RPM), the display will also show you the temperature, media details (track name/performer/radio station, when allowed) and route, if specified. For motorists here in Jacksonville FL who want to gain the greatest out of their time spent on the roadways, having all of this content conveniently available is undoubtedly the smart choice.
Stunning Landscapes Are Merely the Push of a Button Away
A dual-panel panoramic sunroof enhances the cabin by letting you and any passengers enjoy those just right Jacksonville days. Along with the multitude of other simple pleasures that accompany purchasing or leasing a revamped Jeep Compass, being thankful for a bit of fresh air and the sunshine on your face is definitely one of the better techniques to make the most out of your everyday commute or an out-of-town trip. As you can tell, there is no time like currently to know firsthand unconfined freedom via a fully-equipped Jeep Compass sitting in your front driveway.
Safety Is Forever Trendy with a Modern Jeep Compass
Here at Jacksonville CJDR Westside, we responsibly stand behind the commitment of presenting only the safest and most dependable vehicles to our friends in Jacksonville. With this notion, you should expect nothing but the best in relation to Jeep's duty to safety with the new Compass SUVs spotlighted for you on our showroom floor. In particular, positioned in the driver's seat of this division-leading SUV guarantees you have a chance to access a plethora of top-grade safety features, including:
- Seven airbags
- LaneSense Lane Departure Warning with Lane Keep Assist
- Blind Spot Monitoring System
- Active Braking
- Forward Collision Warning
- ParkView Rear Backup Camera
- ParkSense Rear Park Assist with Cross Path Detection
Jeep has created an ideal blend of coziness and functionality in the all-new Compass model, and as a result, we at Jacksonville CJDR Westside are excited to present it to customers on the lookout for a SUV that can stand out in more than one aspect. Sturdy yet appealing, affordable, and highly regarded, the new Compass is the one to outdo, so visit us to review our purchasing and leasing options.
Trim Level Market Research
Jeep Compass
- Altitude 4x4
- Starting From: $25,095
Pricing
Starting From $25,095
Destination Charge $1,495
Chassis
Base Curb Weight 3327
Dead Weight Hitch - Max Trailer Wt. 1000
Dead Weight Hitch - Max Tongue Wt. 100
Wt Distributing Hitch - Max Trailer Wt. 1000
Wt Distributing Hitch - Max Tongue Wt. 100
Maximum Trailering Capacity 1000
Suspension Type - Front Strut
Suspension Type - Rear Strut
Suspension Type - Front (Cont.) Strut
Suspension Type - Rear (Cont.) Strut
Front Tire Order Code TWL
Rear Tire Order Code TWL
Spare Tire Order Code TBS
Front Tire Size P225/55HR18
Rear Tire Size P225/55HR18
Spare Tire Size Full-Size
Front Wheel Size 18 X 7
Rear Wheel Size 18 X 7
Spare Wheel Size Full-Size
Front Wheel Material Aluminum
Rear Wheel Material Aluminum
Spare Wheel Material Steel
Steering Type Rack-Pinion
Turning Diameter - Curb to Curb 36.3
Brake Type 4-Wheel Disc
Brake ABS System 4-Wheel
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 12
Rear Brake Rotor Diam x Thickness 11
Fuel Tank Capacity, Approx 13.5
Powertrain
Drivetrain Four Wheel Drive
Fuel Economy Est-Combined 25
EPA Fuel Economy Est - City 22
EPA Fuel Economy Est - Hwy 30
Engine Order Code EDE
Engine Type Regular Unleaded I-4
Displacement 2.4 L/144
Fuel System Sequential MPI
SAE Net Horsepower @ RPM 180 @ 6400
SAE Net Torque @ RPM 175 @ 3900
Trans Order Code DFH
Trans Type 9
Trans Description Cont. Automatic w/OD
First Gear Ratio (:1) 4.71
Second Gear Ratio (:1) 2.84
Third Gear Ratio (:1) 1.91
Fourth Gear Ratio (:1) 1.38
Fifth Gear Ratio (:1) 1.00
Sixth Gear Ratio (:1) 0.81
Reverse Ratio (:1) 3.81
Final Drive Axle Ratio (:1) 3.73
Cold Cranking Amps @ 0° F (Primary) 500
Maximum Alternator Capacity (amps) 160
Seventh Gear Ratio (:1) 0.70
Eighth Gear Ratio (:1) 0.58
Engine Displacement Units 2.4
Engine Camshaft SOHC
Engine Block Type aluminum
Engine Cylinder Count 4
Engine Valve Count 4
Dimensions
Passenger Capacity 5
Passenger Volume 99.6
Front Head Room 39.2
Front Leg Room 41.8
Front Shoulder Room 56.7
Front Hip Room 54.1
Second Head Room 38.5
Second Leg Room 38.3
Second Shoulder Room 55.1
Second Hip Room 49.2
Wheelbase 103.8
Width, Max w/o mirrors 73.8
Height, Overall 64.8
Track Width, Front 60.7
Track Width, Rear 60.3
Min Ground Clearance 8.2
Cargo Area Width @ Beltline 42.1
Cargo Box Width @ Wheelhousings 38.1
Cargo Box (Area) Height 27.2
Liftover Height 29.7
Cargo Volume to Seat 1 59.8
Cargo Volume to Seat 2 27.2
Cargo Volume to Seat 3 27.2
Warranty
Basic Years 3
Basic Miles/km 36,000
Drivetrain Years 5
Drivetrain Miles/km 60,000
Corrosion Years 5
Corrosion Miles/km Unlimited
Roadside Assistance Years 5
Roadside Assistance Miles/km 60,000
Jeep Compass
- Altitude FWD
- Starting From: $25,095
Pricing
Starting From $25,095
Destination Charge $1,495
Chassis
Base Curb Weight 3184
Dead Weight Hitch - Max Trailer Wt. 1000
Dead Weight Hitch - Max Tongue Wt. 100
Wt Distributing Hitch - Max Trailer Wt. 1000
Wt Distributing Hitch - Max Tongue Wt. 100
Maximum Trailering Capacity 1000
Suspension Type - Front Strut
Suspension Type - Rear Strut
Suspension Type - Front (Cont.) Strut
Suspension Type - Rear (Cont.) Strut
Front Tire Order Code TWL
Rear Tire Order Code TWL
Spare Tire Order Code TBC
Front Tire Size P225/55HR18
Rear Tire Size P225/55HR18
Spare Tire Size Compact
Front Wheel Size 18 X 7
Rear Wheel Size 18 X 7
Spare Wheel Size Compact
Front Wheel Material Aluminum
Rear Wheel Material Aluminum
Spare Wheel Material Steel
Steering Type Rack-Pinion
Turning Diameter - Curb to Curb 36.3
Brake Type 4-Wheel Disc
Brake ABS System 4-Wheel
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 12
Rear Brake Rotor Diam x Thickness 11
Fuel Tank Capacity, Approx 13.5
Powertrain
Drivetrain Front Wheel Drive
Fuel Economy Est-Combined 25
EPA Fuel Economy Est - City 22
EPA Fuel Economy Est - Hwy 31
Engine Order Code EDE
Engine Type Regular Unleaded I-4
Displacement 2.4 L/144
Fuel System Sequential MPI
SAE Net Horsepower @ RPM 180 @ 6400
SAE Net Torque @ RPM 175 @ 3900
Trans Order Code DF7
Trans Type 6
Trans Description Cont. Automatic w/OD
First Gear Ratio (:1) 4.46
Second Gear Ratio (:1) 2.51
Third Gear Ratio (:1) 1.56
Fourth Gear Ratio (:1) 1.14
Fifth Gear Ratio (:1) 0.85
Sixth Gear Ratio (:1) 0.67
Final Drive Axle Ratio (:1) 3.50
Cold Cranking Amps @ 0° F (Primary) 500
Maximum Alternator Capacity (amps) 160
Engine Displacement Units 2.4
Engine Camshaft SOHC
Engine Block Type aluminum
Engine Cylinder Count 4
Engine Valve Count 4
Dimensions
Passenger Capacity 5
Passenger Volume 99.6
Front Head Room 39.2
Front Leg Room 41.8
Front Shoulder Room 56.7
Front Hip Room 54.1
Second Head Room 38.5
Second Leg Room 38.3
Second Shoulder Room 55.1
Second Hip Room 49.2
Wheelbase 103.8
Width, Max w/o mirrors 73.8
Height, Overall 64.8
Track Width, Front 60.7
Track Width, Rear 60.3
Min Ground Clearance 7.8
Cargo Area Width @ Beltline 42.1
Cargo Box Width @ Wheelhousings 38.1
Cargo Box (Area) Height 27.2
Liftover Height 29.7
Cargo Volume to Seat 1 59.8
Cargo Volume to Seat 2 27.2
Cargo Volume to Seat 3 27.2
Warranty
Basic Years 3
Basic Miles/km 36,000
Drivetrain Years 5
Drivetrain Miles/km 60,000
Corrosion Years 5
Corrosion Miles/km Unlimited
Roadside Assistance Years 5
Roadside Assistance Miles/km 60,000
Jeep Compass
- High Altitude 4x4
- Starting From: $29,695
Pricing
Starting From $29,695
Destination Charge $1,495
Chassis
Base Curb Weight 3327
Dead Weight Hitch - Max Trailer Wt. 1000
Dead Weight Hitch - Max Tongue Wt. 100
Wt Distributing Hitch - Max Trailer Wt. 1000
Wt Distributing Hitch - Max Tongue Wt. 100
Maximum Trailering Capacity 1000
Suspension Type - Front Strut
Suspension Type - Rear Strut
Suspension Type - Front (Cont.) Strut
Suspension Type - Rear (Cont.) Strut
Front Tire Order Code TPS
Rear Tire Order Code TPS
Spare Tire Order Code TBS
Front Tire Size P235/45HR19
Rear Tire Size P235/45HR19
Spare Tire Size Full-Size
Front Wheel Size 19 X 7.5
Rear Wheel Size 19 X 7.5
Spare Wheel Size Full-Size
Front Wheel Material Aluminum
Rear Wheel Material Aluminum
Spare Wheel Material Steel
Steering Type Rack-Pinion
Turning Diameter - Curb to Curb 36.3
Brake Type 4-Wheel Disc
Brake ABS System 4-Wheel
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 12
Rear Brake Rotor Diam x Thickness 11
Fuel Tank Capacity, Approx 13.5
Powertrain
Drivetrain Four Wheel Drive
Fuel Economy Est-Combined 25
EPA Fuel Economy Est - City 22
EPA Fuel Economy Est - Hwy 30
Engine Order Code EDE
Engine Type Regular Unleaded I-4
Displacement 2.4 L/144
Fuel System Sequential MPI
SAE Net Horsepower @ RPM 180 @ 6400
SAE Net Torque @ RPM 175 @ 3900
Trans Order Code DFH
Trans Type 9
Trans Description Cont. Automatic w/OD
First Gear Ratio (:1) 4.71
Second Gear Ratio (:1) 2.84
Third Gear Ratio (:1) 1.91
Fourth Gear Ratio (:1) 1.38
Fifth Gear Ratio (:1) 1.00
Sixth Gear Ratio (:1) 0.81
Reverse Ratio (:1) 3.81
Final Drive Axle Ratio (:1) 3.73
Cold Cranking Amps @ 0° F (Primary) 500
Maximum Alternator Capacity (amps) 160
Seventh Gear Ratio (:1) 0.70
Eighth Gear Ratio (:1) 0.58
Engine Displacement Units 2.4
Engine Camshaft SOHC
Engine Block Type aluminum
Engine Cylinder Count 4
Engine Valve Count 4
Dimensions
Passenger Capacity 5
Passenger Volume 99.6
Front Head Room 39.2
Front Leg Room 41.8
Front Shoulder Room 56.7
Front Hip Room 54.1
Second Head Room 38.5
Second Leg Room 38.3
Second Shoulder Room 55.1
Second Hip Room 49.2
Wheelbase 103.8
Width, Max w/o mirrors 73.8
Height, Overall 64.8
Track Width, Front 60.7
Track Width, Rear 60.3
Min Ground Clearance 8.2
Cargo Area Width @ Beltline 42.1
Cargo Box Width @ Wheelhousings 38.1
Cargo Box (Area) Height 27.2
Liftover Height 29.7
Cargo Volume to Seat 1 59.8
Cargo Volume to Seat 2 27.2
Cargo Volume to Seat 3 27.2
Warranty
Basic Years 3
Basic Miles/km 36,000
Drivetrain Years 5
Drivetrain Miles/km 60,000
Corrosion Years 5
Corrosion Miles/km Unlimited
Roadside Assistance Years 5
Roadside Assistance Miles/km 60,000
Jeep Compass
- High Altitude FWD
- Starting From: $28,195
Pricing
Starting From $28,195
Destination Charge $1,495
Chassis
Base Curb Weight 3184
Dead Weight Hitch - Max Trailer Wt. 1000
Dead Weight Hitch - Max Tongue Wt. 100
Wt Distributing Hitch - Max Trailer Wt. 1000
Wt Distributing Hitch - Max Tongue Wt. 100
Maximum Trailering Capacity 1000
Suspension Type - Front Strut
Suspension Type - Rear Strut
Suspension Type - Front (Cont.) Strut
Suspension Type - Rear (Cont.) Strut
Front Tire Order Code TPS
Rear Tire Order Code TPS
Spare Tire Order Code TBC
Front Tire Size P235/45HR19
Rear Tire Size P235/45HR19
Spare Tire Size Compact
Front Wheel Size 19 X 7.5
Rear Wheel Size 19 X 7.5
Spare Wheel Size Compact
Front Wheel Material Aluminum
Rear Wheel Material Aluminum
Spare Wheel Material Steel
Steering Type Rack-Pinion
Turning Diameter - Curb to Curb 36.3
Brake Type 4-Wheel Disc
Brake ABS System 4-Wheel
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 12
Rear Brake Rotor Diam x Thickness 11
Fuel Tank Capacity, Approx 13.5
Powertrain
Drivetrain Front Wheel Drive
Fuel Economy Est-Combined 25
EPA Fuel Economy Est - City 22
EPA Fuel Economy Est - Hwy 31
Engine Order Code EDE
Engine Type Regular Unleaded I-4
Displacement 2.4 L/144
Fuel System Sequential MPI
SAE Net Horsepower @ RPM 180 @ 6400
SAE Net Torque @ RPM 175 @ 3900
Trans Order Code DF7
Trans Type 6
Trans Description Cont. Automatic w/OD
First Gear Ratio (:1) 4.46
Second Gear Ratio (:1) 2.51
Third Gear Ratio (:1) 1.56
Fourth Gear Ratio (:1) 1.14
Fifth Gear Ratio (:1) 0.85
Sixth Gear Ratio (:1) 0.67
Final Drive Axle Ratio (:1) 3.50
Cold Cranking Amps @ 0° F (Primary) 500
Maximum Alternator Capacity (amps) 160
Engine Displacement Units 2.4
Engine Camshaft SOHC
Engine Block Type aluminum
Engine Cylinder Count 4
Engine Valve Count 4
Dimensions
Passenger Capacity 5
Passenger Volume 99.6
Front Head Room 39.2
Front Leg Room 41.8
Front Shoulder Room 56.7
Front Hip Room 54.1
Second Head Room 38.5
Second Leg Room 38.3
Second Shoulder Room 55.1
Second Hip Room 49.2
Wheelbase 103.8
Width, Max w/o mirrors 73.8
Height, Overall 64.8
Track Width, Front 60.7
Track Width, Rear 60.3
Min Ground Clearance 7.8
Cargo Area Width @ Beltline 42.1
Cargo Box Width @ Wheelhousings 38.1
Cargo Box (Area) Height 27.2
Liftover Height 29.7
Cargo Volume to Seat 1 59.8
Cargo Volume to Seat 2 27.2
Cargo Volume to Seat 3 27.2
Warranty
Basic Years 3
Basic Miles/km 36,000
Drivetrain Years 5
Drivetrain Miles/km 60,000
Corrosion Years 5
Corrosion Miles/km Unlimited
Roadside Assistance Years 5
Roadside Assistance Miles/km 60,000
Jeep Compass
- Latitude 4x4
- Starting From: $25,095
Pricing
Starting From $25,095
Destination Charge $1,495
Chassis
Base Curb Weight 3327
Dead Weight Hitch - Max Trailer Wt. 1000
Dead Weight Hitch - Max Tongue Wt. 100
Wt Distributing Hitch - Max Trailer Wt. 1000
Wt Distributing Hitch - Max Tongue Wt. 100
Maximum Trailering Capacity 1000
Suspension Type - Front Strut
Suspension Type - Rear Strut
Suspension Type - Front (Cont.) Strut
Suspension Type - Rear (Cont.) Strut
Front Tire Order Code TJC
Rear Tire Order Code TJC
Spare Tire Order Code TBS
Front Tire Size P225/55HR18
Rear Tire Size P225/55HR18
Spare Tire Size Full-Size
Front Wheel Size 17 X 7
Rear Wheel Size 17 X 7
Spare Wheel Size Full-Size
Front Wheel Material Aluminum
Rear Wheel Material Aluminum
Spare Wheel Material Steel
Steering Type Rack-Pinion
Turning Diameter - Curb to Curb 36.3
Brake Type 4-Wheel Disc
Brake ABS System 4-Wheel
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 12
Rear Brake Rotor Diam x Thickness 11
Fuel Tank Capacity, Approx 13.5
Powertrain
Drivetrain Four Wheel Drive
Fuel Economy Est-Combined 25
EPA Fuel Economy Est - City 22
EPA Fuel Economy Est - Hwy 31
Engine Order Code ED6
Engine Type Regular Unleaded I-4
Displacement 2.4 L/144
Fuel System Sequential MPI
SAE Net Horsepower @ RPM 180 @ 6400
SAE Net Torque @ RPM 175 @ 3900
Trans Order Code DE1
Trans Type 6
Trans Description Cont. Manual w/OD
First Gear Ratio (:1) 4.15
Second Gear Ratio (:1) 2.12
Third Gear Ratio (:1) 1.36
Fourth Gear Ratio (:1) 0.98
Fifth Gear Ratio (:1) 0.76
Sixth Gear Ratio (:1) 0.62
Reverse Ratio (:1) 4.00
Final Drive Axle Ratio (:1) 3.73
Cold Cranking Amps @ 0° F (Primary) 500
Maximum Alternator Capacity (amps) 160
Seventh Gear Ratio (:1) 0.70
Eighth Gear Ratio (:1) 0.58
Engine Displacement Units 2.4
Engine Camshaft SOHC
Engine Block Type aluminum
Engine Cylinder Count 4
Engine Valve Count 4
Dimensions
Passenger Capacity 5
Passenger Volume 99.6
Front Head Room 39.2
Front Leg Room 41.8
Front Shoulder Room 56.7
Front Hip Room 54.1
Second Head Room 38.5
Second Leg Room 38.3
Second Shoulder Room 55.1
Second Hip Room 49.2
Wheelbase 103.8
Width, Max w/o mirrors 73.8
Height, Overall 64.8
Track Width, Front 60.7
Track Width, Rear 60.3
Min Ground Clearance 8.2
Cargo Area Width @ Beltline 42.1
Cargo Box Width @ Wheelhousings 38.1
Cargo Box (Area) Height 27.2
Liftover Height 29.7
Cargo Volume to Seat 1 59.8
Cargo Volume to Seat 2 27.2
Cargo Volume to Seat 3 27.2
Warranty
Basic Years 3
Basic Miles/km 36,000
Drivetrain Years 5
Drivetrain Miles/km 60,000
Corrosion Years 5
Corrosion Miles/km Unlimited
Roadside Assistance Years 5
Roadside Assistance Miles/km 60,000
Jeep Compass
- Latitude FWD
- Starting From: $25,095
Pricing
Starting From $25,095
Destination Charge $1,495
Chassis
Base Curb Weight 3184
Dead Weight Hitch - Max Trailer Wt. 1000
Dead Weight Hitch - Max Tongue Wt. 100
Wt Distributing Hitch - Max Trailer Wt. 1000
Wt Distributing Hitch - Max Tongue Wt. 100
Maximum Trailering Capacity 1000
Suspension Type - Front Strut
Suspension Type - Rear Strut
Suspension Type - Front (Cont.) Strut
Suspension Type - Rear (Cont.) Strut
Front Tire Order Code TJC
Rear Tire Order Code TJC
Spare Tire Order Code TBC
Front Tire Size P225/55R18
Rear Tire Size P225/55R18
Spare Tire Size Compact
Front Wheel Size 17 X 7
Rear Wheel Size 17 X 7
Spare Wheel Size Compact
Front Wheel Material Aluminum
Rear Wheel Material Aluminum
Spare Wheel Material Steel
Steering Type Rack-Pinion
Turning Diameter - Curb to Curb 36.3
Brake Type 4-Wheel Disc
Brake ABS System 4-Wheel
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 12
Rear Brake Rotor Diam x Thickness 11
Fuel Tank Capacity, Approx 13.5
Powertrain
Drivetrain Front Wheel Drive
Fuel Economy Est-Combined 25
EPA Fuel Economy Est - City 22
EPA Fuel Economy Est - Hwy 31
Engine Order Code EDE
Engine Type Regular Unleaded I-4
Displacement 2.4 L/144
Fuel System Sequential MPI
SAE Net Horsepower @ RPM 180 @ 6400
SAE Net Torque @ RPM 175 @ 3900
Trans Order Code DF7
Trans Type 6
Trans Description Cont. Automatic w/OD
First Gear Ratio (:1) 4.46
Second Gear Ratio (:1) 2.51
Third Gear Ratio (:1) 1.56
Fourth Gear Ratio (:1) 1.14
Fifth Gear Ratio (:1) 0.85
Sixth Gear Ratio (:1) 0.67
Final Drive Axle Ratio (:1) 3.50
Cold Cranking Amps @ 0° F (Primary) 500
Maximum Alternator Capacity (amps) 160
Engine Displacement Units 2.4
Engine Camshaft SOHC
Engine Block Type aluminum
Engine Cylinder Count 4
Engine Valve Count 4
Dimensions
Passenger Capacity 5
Passenger Volume 99.6
Front Head Room 39.2
Front Leg Room 41.8
Front Shoulder Room 56.7
Front Hip Room 54.1
Second Head Room 38.5
Second Leg Room 38.3
Second Shoulder Room 55.1
Second Hip Room 49.2
Wheelbase 103.8
Width, Max w/o mirrors 73.8
Height, Overall 64.8
Track Width, Front 60.7
Track Width, Rear 60.3
Min Ground Clearance 7.8
Cargo Area Width @ Beltline 42.1
Cargo Box Width @ Wheelhousings 38.1
Cargo Box (Area) Height 27.2
Liftover Height 29.7
Cargo Volume to Seat 1 59.8
Cargo Volume to Seat 2 27.2
Cargo Volume to Seat 3 27.2
Warranty
Basic Years 3
Basic Miles/km 36,000
Drivetrain Years 5
Drivetrain Miles/km 60,000
Corrosion Years 5
Corrosion Miles/km Unlimited
Roadside Assistance Years 5
Roadside Assistance Miles/km 60,000
Jeep Compass
- Limited 4x4
- Starting From: $29,695
Pricing
Starting From $29,695
Destination Charge $1,495
Chassis
Base Curb Weight 3327
Dead Weight Hitch - Max Trailer Wt. 1000
Dead Weight Hitch - Max Tongue Wt. 100
Wt Distributing Hitch - Max Trailer Wt. 1000
Wt Distributing Hitch - Max Tongue Wt. 100
Maximum Trailering Capacity 1000
Suspension Type - Front Strut
Suspension Type - Rear Strut
Suspension Type - Front (Cont.) Strut
Suspension Type - Rear (Cont.) Strut
Front Tire Order Code TPS
Rear Tire Order Code TPS
Spare Tire Order Code TBS
Front Tire Size P235/45HR19
Rear Tire Size P235/45HR19
Spare Tire Size Full-Size
Front Wheel Size 19 X 7.5
Rear Wheel Size 19 X 7.5
Spare Wheel Size Full-Size
Front Wheel Material Aluminum
Rear Wheel Material Aluminum
Spare Wheel Material Steel
Steering Type Rack-Pinion
Turning Diameter - Curb to Curb 36.3
Brake Type 4-Wheel Disc
Brake ABS System 4-Wheel
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 12
Rear Brake Rotor Diam x Thickness 11
Fuel Tank Capacity, Approx 13.5
Powertrain
Drivetrain Four Wheel Drive
Fuel Economy Est-Combined 25
EPA Fuel Economy Est - City 22
EPA Fuel Economy Est - Hwy 30
Engine Order Code EDE
Engine Type Regular Unleaded I-4
Displacement 2.4 L/144
Fuel System Sequential MPI
SAE Net Horsepower @ RPM 180 @ 6400
SAE Net Torque @ RPM 175 @ 3900
Trans Order Code DFH
Trans Type 9
Trans Description Cont. Automatic w/OD
First Gear Ratio (:1) 4.71
Second Gear Ratio (:1) 2.84
Third Gear Ratio (:1) 1.91
Fourth Gear Ratio (:1) 1.38
Fifth Gear Ratio (:1) 1.00
Sixth Gear Ratio (:1) 0.81
Reverse Ratio (:1) 3.81
Final Drive Axle Ratio (:1) 3.73
Cold Cranking Amps @ 0° F (Primary) 500
Maximum Alternator Capacity (amps) 160
Seventh Gear Ratio (:1) 0.70
Eighth Gear Ratio (:1) 0.58
Engine Displacement Units 2.4
Engine Camshaft SOHC
Engine Block Type aluminum
Engine Cylinder Count 4
Engine Valve Count 4
Dimensions
Passenger Capacity 5
Passenger Volume 99.6
Front Head Room 39.2
Front Leg Room 41.8
Front Shoulder Room 56.7
Front Hip Room 54.1
Second Head Room 38.5
Second Leg Room 38.3
Second Shoulder Room 55.1
Second Hip Room 49.2
Wheelbase 103.8
Width, Max w/o mirrors 73.8
Height, Overall 64.8
Track Width, Front 60.7
Track Width, Rear 60.3
Min Ground Clearance 8.2
Cargo Area Width @ Beltline 42.1
Cargo Box Width @ Wheelhousings 38.1
Cargo Box (Area) Height 27.2
Liftover Height 29.7
Cargo Volume to Seat 1 59.8
Cargo Volume to Seat 2 27.2
Cargo Volume to Seat 3 27.2
Warranty
Basic Years 3
Basic Miles/km 36,000
Drivetrain Years 5
Drivetrain Miles/km 60,000
Corrosion Years 5
Corrosion Miles/km Unlimited
Roadside Assistance Years 5
Roadside Assistance Miles/km 60,000
Jeep Compass
- Limited FWD
- Starting From: $28,195
Pricing
Starting From $28,195
Destination Charge $1,495
Chassis
Base Curb Weight 3184
Dead Weight Hitch - Max Trailer Wt. 1000
Dead Weight Hitch - Max Tongue Wt. 100
Wt Distributing Hitch - Max Trailer Wt. 1000
Wt Distributing Hitch - Max Tongue Wt. 100
Maximum Trailering Capacity 1000
Suspension Type - Front Strut
Suspension Type - Rear Strut
Suspension Type - Front (Cont.) Strut
Suspension Type - Rear (Cont.) Strut
Front Tire Order Code TPS
Rear Tire Order Code TPS
Spare Tire Order Code TBC
Front Tire Size P225/55R18
Rear Tire Size P225/55R18
Spare Tire Size Compact
Front Wheel Size 19 X 7.5
Rear Wheel Size 19 X 7.5
Spare Wheel Size Compact
Front Wheel Material Aluminum
Rear Wheel Material Aluminum
Spare Wheel Material Steel
Steering Type Rack-Pinion
Turning Diameter - Curb to Curb 36.3
Brake Type 4-Wheel Disc
Brake ABS System 4-Wheel
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 12
Rear Brake Rotor Diam x Thickness 11
Fuel Tank Capacity, Approx 13.5
Powertrain
Drivetrain Front Wheel Drive
Fuel Economy Est-Combined 25
EPA Fuel Economy Est - City 22
EPA Fuel Economy Est - Hwy 31
Engine Order Code EDE
Engine Type Regular Unleaded I-4
Displacement 2.4 L/144
Fuel System Sequential MPI
SAE Net Horsepower @ RPM 180 @ 6400
SAE Net Torque @ RPM 175 @ 3900
Trans Order Code DF7
Trans Type 6
Trans Description Cont. Automatic w/OD
First Gear Ratio (:1) 4.46
Second Gear Ratio (:1) 2.51
Third Gear Ratio (:1) 1.56
Fourth Gear Ratio (:1) 1.14
Fifth Gear Ratio (:1) 0.85
Sixth Gear Ratio (:1) 0.67
Final Drive Axle Ratio (:1) 3.50
Cold Cranking Amps @ 0° F (Primary) 500
Maximum Alternator Capacity (amps) 160
Engine Displacement Units 2.4
Engine Camshaft SOHC
Engine Block Type aluminum
Engine Cylinder Count 4
Engine Valve Count 4
Dimensions
Passenger Capacity 5
Passenger Volume 99.6
Front Head Room 39.2
Front Leg Room 41.8
Front Shoulder Room 56.7
Front Hip Room 54.1
Second Head Room 38.5
Second Leg Room 38.3
Second Shoulder Room 55.1
Second Hip Room 49.2
Wheelbase 103.8
Width, Max w/o mirrors 73.8
Height, Overall 64.8
Track Width, Front 60.7
Track Width, Rear 60.3
Min Ground Clearance 7.8
Cargo Area Width @ Beltline 42.1
Cargo Box Width @ Wheelhousings 38.1
Cargo Box (Area) Height 27.2
Liftover Height 29.7
Cargo Volume to Seat 1 59.8
Cargo Volume to Seat 2 27.2
Cargo Volume to Seat 3 27.2
Warranty
Basic Years 3
Basic Miles/km 36,000
Drivetrain Years 5
Drivetrain Miles/km 60,000
Corrosion Years 5
Corrosion Miles/km Unlimited
Roadside Assistance Years 5
Roadside Assistance Miles/km 60,000
Jeep Compass
- Sport 4x4
- Starting From: $23,345
Pricing
Starting From $23,345
Destination Charge $1,495
Chassis
Base Curb Weight 3327
Dead Weight Hitch - Max Trailer Wt. 1000
Dead Weight Hitch - Max Tongue Wt. 100
Wt Distributing Hitch - Max Trailer Wt. 1000
Wt Distributing Hitch - Max Tongue Wt. 100
Maximum Trailering Capacity 1000
Suspension Type - Front Strut
Suspension Type - Rear Strut
Suspension Type - Front (Cont.) Strut
Suspension Type - Rear (Cont.) Strut
Front Tire Order Code TM9
Rear Tire Order Code TM9
Spare Tire Order Code TBC
Front Tire Size P215/65HR16
Rear Tire Size P215/65HR16
Spare Tire Size Compact
Front Wheel Size 16 X 6.5
Rear Wheel Size 16 X 6.5
Spare Wheel Size Compact
Front Wheel Material Styled Steel
Rear Wheel Material Styled Steel
Spare Wheel Material Steel
Steering Type Rack-Pinion
Turning Diameter - Curb to Curb 36.3
Brake Type 4-Wheel Disc
Brake ABS System 4-Wheel
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 12
Rear Brake Rotor Diam x Thickness 11
Fuel Tank Capacity, Approx 13.5
Powertrain
Drivetrain Four Wheel Drive
Fuel Economy Est-Combined 25
EPA Fuel Economy Est - City 22
EPA Fuel Economy Est - Hwy 31
Engine Order Code ED6
Engine Type Regular Unleaded I-4
Displacement 2.4 L/144
Fuel System Sequential MPI
SAE Net Horsepower @ RPM 180 @ 6400
SAE Net Torque @ RPM 175 @ 3900
Trans Order Code DE1
Trans Type 6
Trans Description Cont. Manual w/OD
First Gear Ratio (:1) 4.15
Second Gear Ratio (:1) 2.12
Third Gear Ratio (:1) 1.36
Fourth Gear Ratio (:1) 0.98
Fifth Gear Ratio (:1) 0.76
Sixth Gear Ratio (:1) 0.62
Reverse Ratio (:1) 4.00
Final Drive Axle Ratio (:1) 3.83
Cold Cranking Amps @ 0° F (Primary) 500
Maximum Alternator Capacity (amps) 160
Seventh Gear Ratio (:1) 0.70
Eighth Gear Ratio (:1) 0.58
Engine Displacement Units 2.4
Engine Camshaft SOHC
Engine Block Type aluminum
Engine Cylinder Count 4
Engine Valve Count 4
Dimensions
Passenger Capacity 5
Passenger Volume 99.6
Front Head Room 39.2
Front Leg Room 41.8
Front Shoulder Room 56.7
Front Hip Room 54.1
Second Head Room 38.5
Second Leg Room 38.3
Second Shoulder Room 55.1
Second Hip Room 49.2
Wheelbase 103.8
Width, Max w/o mirrors 73.8
Height, Overall 64.6
Track Width, Front 60.7
Track Width, Rear 60.3
Min Ground Clearance 8.2
Cargo Area Width @ Beltline 42.1
Cargo Box Width @ Wheelhousings 38.1
Cargo Box (Area) Height 27.2
Liftover Height 29.7
Cargo Volume to Seat 1 59.8
Cargo Volume to Seat 2 27.2
Cargo Volume to Seat 3 27.2
Warranty
Basic Years 3
Basic Miles/km 36,000
Drivetrain Years 5
Drivetrain Miles/km 60,000
Corrosion Years 5
Corrosion Miles/km Unlimited
Roadside Assistance Years 5
Roadside Assistance Miles/km 60,000
Jeep Compass
- Sport FWD
- Starting From: $21,845
Pricing
Starting From $21,845
Destination Charge $1,495
Chassis
Base Curb Weight 3184
Dead Weight Hitch - Max Trailer Wt. 1000
Dead Weight Hitch - Max Tongue Wt. 100
Wt Distributing Hitch - Max Trailer Wt. 1000
Wt Distributing Hitch - Max Tongue Wt. 100
Maximum Trailering Capacity 1000
Suspension Type - Front Strut
Suspension Type - Rear Strut
Suspension Type - Front (Cont.) Strut
Suspension Type - Rear (Cont.) Strut
Front Tire Order Code TM9
Rear Tire Order Code TM9
Spare Tire Order Code TBC
Front Tire Size P215/65HR16
Rear Tire Size P215/65HR16
Spare Tire Size Compact
Front Wheel Size 16 X 6.5
Rear Wheel Size 16 X 6.5
Spare Wheel Size Compact
Front Wheel Material Styled Steel
Rear Wheel Material Styled Steel
Spare Wheel Material Steel
Steering Type Rack-Pinion
Turning Diameter - Curb to Curb 36.3
Brake Type 4-Wheel Disc
Brake ABS System 4-Wheel
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 12
Rear Brake Rotor Diam x Thickness 11
Fuel Tank Capacity, Approx 13.5
Powertrain
Drivetrain Front Wheel Drive
Fuel Economy Est-Combined 26
EPA Fuel Economy Est - City 23
EPA Fuel Economy Est - Hwy 32
Engine Order Code ED6
Engine Type Regular Unleaded I-4
Displacement 2.4 L/144
Fuel System Sequential MPI
SAE Net Horsepower @ RPM 180 @ 6400
SAE Net Torque @ RPM 175 @ 3900
Trans Order Code DF7
Trans Type 6
Trans Description Cont. Automatic w/OD
First Gear Ratio (:1) 4.46
Second Gear Ratio (:1) 2.51
Third Gear Ratio (:1) 1.56
Fourth Gear Ratio (:1) 1.14
Fifth Gear Ratio (:1) 0.85
Sixth Gear Ratio (:1) 0.67
Reverse Ratio (:1) 4.00
Final Drive Axle Ratio (:1) 3.83
Cold Cranking Amps @ 0° F (Primary) 500
Maximum Alternator Capacity (amps) 160
Engine Displacement Units 2.4
Engine Camshaft SOHC
Engine Block Type aluminum
Engine Cylinder Count 4
Engine Valve Count 4
Dimensions
Passenger Capacity 5
Passenger Volume 99.6
Front Head Room 39.2
Front Leg Room 41.8
Front Shoulder Room 56.7
Front Hip Room 54.1
Second Head Room 38.5
Second Leg Room 38.3
Second Shoulder Room 55.1
Second Hip Room 49.2
Wheelbase 103.8
Width, Max w/o mirrors 73.8
Height, Overall 64.6
Track Width, Front 60.7
Track Width, Rear 60.3
Min Ground Clearance 7.8
Cargo Area Width @ Beltline 42.1
Cargo Box Width @ Wheelhousings 38.1
Cargo Box (Area) Height 27.2
Liftover Height 29.7
Cargo Volume to Seat 1 59.8
Cargo Volume to Seat 2 27.2
Cargo Volume to Seat 3 27.2
Warranty
Basic Years 3
Basic Miles/km 36,000
Drivetrain Years 5
Drivetrain Miles/km 60,000
Corrosion Years 5
Corrosion Miles/km Unlimited
Roadside Assistance Years 5
Roadside Assistance Miles/km 60,000
Jeep Compass
- Trailhawk 4x4
- Starting From: $29,195
Pricing
Starting From $29,195
Destination Charge $1,495
Chassis
Base Curb Weight 3633
Dead Weight Hitch - Max Trailer Wt. 1000
Dead Weight Hitch - Max Tongue Wt. 100
Wt Distributing Hitch - Max Trailer Wt. 1000
Wt Distributing Hitch - Max Tongue Wt. 100
Maximum Trailering Capacity 1000
Suspension Type - Front Strut
Suspension Type - Rear Strut
Suspension Type - Front (Cont.) Strut
Suspension Type - Rear (Cont.) Strut
Front Tire Order Code TAF
Rear Tire Order Code TAF
Front Tire Size P215/65SR17
Rear Tire Size P215/65SR17
Spare Tire Size Full-Size
Front Wheel Size 17 X 6.5
Rear Wheel Size 17 X 6.5
Spare Wheel Size Full-Size
Front Wheel Material Aluminum
Rear Wheel Material Aluminum
Spare Wheel Material Steel
Steering Type Rack-Pinion
Turning Diameter - Curb to Curb 35.3
Brake Type 4-Wheel Disc
Brake ABS System 4-Wheel
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 12
Rear Brake Rotor Diam x Thickness 11
Fuel Tank Capacity, Approx 13.5
Powertrain
Drivetrain Four Wheel Drive
Fuel Economy Est-Combined 25
EPA Fuel Economy Est - City 22
EPA Fuel Economy Est - Hwy 30
Engine Order Code EDE
Engine Type Regular Unleaded I-4
Displacement 2.4 L/144
Fuel System Sequential MPI
SAE Net Horsepower @ RPM 180 @ 6400
SAE Net Torque @ RPM 175 @ 3900
Trans Order Code DFH
Trans Type 9
Trans Description Cont. Automatic w/OD
First Gear Ratio (:1) 4.71
Second Gear Ratio (:1) 2.84
Third Gear Ratio (:1) 1.91
Fourth Gear Ratio (:1) 1.38
Fifth Gear Ratio (:1) 1.00
Sixth Gear Ratio (:1) 0.81
Reverse Ratio (:1) 3.81
Final Drive Axle Ratio (:1) 4.33
Cold Cranking Amps @ 0° F (Primary) 500
Maximum Alternator Capacity (amps) 160
Seventh Gear Ratio (:1) 0.70
Eighth Gear Ratio (:1) 0.58
Engine Displacement Units 2.4
Engine Camshaft SOHC
Engine Block Type aluminum
Engine Cylinder Count 4
Engine Valve Count 4
Dimensions
Passenger Capacity 5
Passenger Volume 99.6
Front Head Room 39.2
Front Leg Room 41.8
Front Shoulder Room 56.7
Front Hip Room 54.1
Second Head Room 38.5
Second Leg Room 38.3
Second Shoulder Room 55.1
Second Hip Room 49.2
Wheelbase 103.8
Width, Max w/o mirrors 73.8
Height, Overall 64.8
Track Width, Front 60.7
Track Width, Rear 60.3
Min Ground Clearance 8.5
Cargo Area Width @ Beltline 42.1
Cargo Box Width @ Wheelhousings 38.1
Cargo Box (Area) Height 27.2
Liftover Height 29.7
Cargo Volume to Seat 1 59.8
Cargo Volume to Seat 2 27.2
Cargo Volume to Seat 3 27.2
